• 3-piece Low Pressure Ball Valves

3-piece Low Pressure Ball Valves

Material:

SS316

Features:

1.Maximum working pressure: 725 psig (50 bar) for casting body.
2.Bi-directional flow on/off service for 2-way pattern.
3.Low torque operation handle with arrow indicates flow direction.
4.Quick operation 1/4 turn on-off control of fluids utilized in process and instrumentation applications.
5.Panel mounted.
6.Each valve is stamped with material and size.
7.Temperature rating range: -20°C~+180°C (-4°F ~ +356°F).

Production Range:

1.Compression End, Metric:(OD)6mm~18mm
   Compression End, Fractional:(OD)1/8"~1"
2.Female Thread:1/8"~1/2"
3.Male Thread:1/8"~3/4"
